Product Introduction
The NI PXIe-8133 is a high-performance PXI Express embedded controller developed for automated test equipment (ATE), modular instrumentation, semiconductor validation, RF measurement, and industrial automation applications. Powered by an Intel® Core™ i7 processor, the PXIe-8133 delivers fast processing performance, reliable PCI Express communication, and seamless integration with National Instruments PXI Express systems.
Designed to operate within PXI Express chassis, the PXIe-8133 provides centralized system control for oscilloscopes, multifunction DAQ modules, RF analyzers, switch modules, source measure units (SMUs), and other PXI Express instruments, enabling engineers to build scalable and reliable automated test platforms.
Product Overview
The PXIe-8133 belongs to the NI PXI Express Embedded Controller family and offers an excellent balance of computing performance, reliability, and expansion capability. Supporting both Windows and LabVIEW Real-Time operating systems, it is suitable for engineering development, production testing, laboratory research, and industrial automation.
Its PCI Express architecture enables high-speed communication with PXI Express modules while reducing latency, allowing synchronized operation of high-speed digitizers, RF instruments, FlexRIO modules, and multifunction DAQ hardware.
Key Features
Intel Core i7 Processor
The PXIe-8133 incorporates an Intel Core i7 processor optimized for demanding engineering applications.
- Intel Core i7 processor
- Multi-core architecture
- High processing performance
- Large processor cache
- Reliable computing platform
Advantage: Delivers excellent computing capability for automated testing, signal processing, and measurement applications.
PXI Express Embedded Architecture
Designed specifically for PXI Express modular instrumentation systems.
- Embedded PXIe controller
- High-speed system control
- Integrated platform management
- Simple installation
- Reliable communication
Advantage: Provides centralized management of complete PXI Express measurement systems.
PCI Express High-Speed Communication
Supports fast communication between the embedded controller and PXI Express modules.
- PCI Express interface
- High-bandwidth communication
- Low-latency operation
- Fast data transfer
- Optimized throughput
Advantage: Maximizes overall performance when controlling high-speed modular instrumentation.
Windows and LabVIEW Real-Time Support
Supports multiple software environments for flexible deployment.
- Microsoft Windows
- LabVIEW Real-Time
- Deterministic applications
- Industrial automation
- Flexible development platform
Advantage: Supports both general-purpose engineering applications and real-time industrial systems.
Reliable Industrial Performance
Designed for continuous operation in laboratory and production environments.
- Industrial-grade reliability
- Continuous operation
- Stable performance
- Long service life
- Low maintenance
Advantage: Provides dependable system operation for mission-critical automated testing.
Technical Specifications
| Parameter | Description |
|---|---|
| Product Type | PXI Express Embedded Controller |
| Processor | Intel® Core™ i7 Processor |
| Architecture | PCI Express |
| Operating System | Windows / LabVIEW Real-Time |
| Memory | DDR3 High-Speed Memory |
| Storage | Solid-State Drive (SSD) |
| Ethernet | Dual Gigabit Ethernet |
| USB | USB 3.0 and USB 2.0 |
| Video Output | DisplayPort |
| Compatible Chassis | PXI Express Chassis |
| Software Support | LabVIEW, LabVIEW Real-Time, TestStand, NI MAX |
| Operating Temperature | 0 °C to 55 °C |
Software Ecosystem
The PXIe-8133 is fully integrated with the National Instruments software ecosystem.
- LabVIEW – Graphical programming for automated measurement and control.
- LabVIEW Real-Time – Deterministic industrial control applications.
- TestStand – Automated production test sequencing.
- NI MAX – Hardware configuration and diagnostics.
- SystemLink – Remote deployment and system management.
- Python, C/C++, C#, and .NET – Supported through NI hardware APIs.
Industries
- Automated Test Equipment (ATE)
- Semiconductor Testing
- Wireless Communications
- Aerospace and Defense
- Industrial Automation
- Electronics Manufacturing
- Automotive Electronics
- Research Laboratories
Applications
Automated Test Systems
Manage synchronized PXI Express instruments for production testing.
- Production testing
- Functional verification
- Electronic validation
- Quality assurance
RF Measurement
Control RF analyzers, vector signal generators, and digitizers.
- RF testing
- 5G validation
- Spectrum analysis
- Wireless communications
High-Speed Data Acquisition
Acquire and process measurement data from multiple PXI Express modules.
- Oscilloscope acquisition
- DAQ systems
- Signal analysis
- Real-time processing
Industrial Automation
Operate modular instrumentation within industrial control systems.
- Machine control
- Factory automation
- Embedded measurement
- System monitoring
Comparison with Similar Products
| Model | Main Difference | Best Application |
|---|---|---|
| NI PXIe-8133 | Intel Core i7 embedded controller offering excellent performance for PXI Express systems. | General high-performance automated testing |
| NI PXIe-8135 | Higher-performance Intel Core i7 embedded controller with newer platform architecture. | Advanced automated testing |
| NI PXIe-8820 | Intel Core i3 controller for entry-level PXI Express systems. | General laboratory applications |
| NI PXIe-8861 | Next-generation Intel Core i7 controller with higher processing capability. | High-end modular instrumentation |
Recommended Related Products
| NI PXIe-1092 | 8-slot PXI Express chassis for compact systems. |
| NI PXIe-1095 | 18-slot high-performance PXI Express chassis. |
| NI PXIe-5164 | High-speed PXI Express oscilloscope. |
| NI PXIe-6378 | High-performance multifunction DAQ module. |
| NI PXIe-5840 | Vector Signal Transceiver for RF measurement applications. |
Why Choose PXIe-8133?
- Intel Core i7 processor for demanding engineering applications
- Optimized for PXI Express modular instrumentation
- High-speed PCI Express communication
- Supports Windows and LabVIEW Real-Time
- Reliable industrial-grade embedded controller
- Excellent for RF, semiconductor, and automated testing
- Compatible with the complete NI software ecosystem
- Scalable platform for advanced measurement systems
Frequently Asked Questions
What is the PXIe-8133 primarily used for?
The PXIe-8133 is designed for automated test equipment, semiconductor validation, RF measurement, industrial automation, modular instrumentation, and high-speed data acquisition applications.
Which PXI Express chassis are compatible with the PXIe-8133?
The PXIe-8133 is compatible with National Instruments PXI Express chassis, including the PXIe-1095, PXIe-1092, PXIe-1088, PXIe-1075, PXIe-1065, and other supported PXIe platforms.
Which software supports the PXIe-8133?
The PXIe-8133 supports LabVIEW, LabVIEW Real-Time, TestStand, NI MAX, SystemLink, Windows, Python, C/C++, C#, .NET, and National Instruments hardware drivers.
Conclusion
The NI PXIe-8133 PXI Express Embedded Controller delivers powerful Intel Core i7 processing, fast PCI Express communication, and seamless integration with the National Instruments software ecosystem. Its excellent performance, industrial reliability, and compatibility with a wide range of PXI Express instrumentation make it an ideal controller for automated testing, RF measurement, semiconductor validation, and advanced modular instrumentation systems.
