PXIe-8880

Земля PXIe-8880 является Встроенный контроллер PXI от Национальные инструменты, designed for processor-intensive RF test, modular instrumentation, data acquisition, and advanced automated measurement systems. As a high-performance embedded controller for PXI Express systems, the NI PXIe-8880 provides the processing power and system control needed to manage multiple PXI and PXIe modules in a single chassis. It features a 2.3 GHz Intel Xeon 8-core processor, making it suitable for demanding PXI Express test platforms. NI lists the PXIe-8880 as no longer available and suggests the PXIe-8881 в качестве модели-замены.

Земля NI PXIe-8880 is used as the main system controller inside a PXI Express chassis. Instead of controlling the chassis with an external desktop computer, engineers can install the PXIe-8880 directly into the chassis to create a compact, integrated, and reliable test system. This design helps reduce external cabling, simplify system setup, and improve system stability in automated test environments.

Для подключения, PXIe-8880 PXI Controller включает два гигабитных Ethernet-порта 10/100/1000BASE-TX, два порта USB 3.0, четыре порта USB 2.0, ан интегрированный жесткий диск, а последовательный порт, and other peripheral I/O. These interfaces allow users to connect network systems, external storage devices, USB peripherals, serial instruments, displays, and other test accessories.

Земля National Instruments PXIe-8880 is suitable for controlling a wide range of PXI and PXI Express modules, including digitizers, oscilloscopes, vector signal transceivers, RF signal analyzers, signal generators, switch modules, source measure units, digital I/O modules, and multifunction DAQ modules. Its 8-core Xeon processor makes it useful for applications where large amounts of measurement data must be acquired, analyzed, stored, or transferred in real time.

The PXIe-8880 is especially useful for РФ тест, многоканальный сбор данных, модульная аппаратура, и Процессороемкие автоматизированные системы тестирования. Engineers can use it to run test software, control multiple instruments, process measurement data, and manage communication between the PXI chassis and external systems. Its dual Gigabit Ethernet and USB interfaces make it practical for systems that require network communication, peripheral expansion, and high-speed data movement.

In terms of physical installation, the PXIe-8880 является four-wide 3U PXI Express module that requires one system slot plus three controller expansion slots. It is fully compatible with the PXI Express Specification 1.0 and has a typical weight of 1.5 kg / 3.4 lb. The controller is designed for indoor use and operates within an ambient temperature range of 0 °C to 50 °C, with a storage temperature range of -40 °C to 71 °C.

Земля PXIe-8880 Embedded Controller is suitable for semiconductor test, aerospace and defense validation, wireless communication testing, production test stations, laboratory automation, and industrial measurement systems. For users who need more processing capability than entry-level PXI controllers, the PXIe-8880 provides an 8-core platform for complex modular test systems.

В целом, NI PXIe-8880 PXI Embedded Controller является высокопроизводительным контроллером для систем PXI Express. С его 2.3 GHz Intel Xeon 8-core processor, dual Gigabit Ethernet, USB 3.0, USB 2.0, serial port, integrated storage, and PXI Express platform compatibility, the PXIe-8880 is well suited for RF measurement, modular instrumentation, data acquisition, and advanced automated test applications.
