Product Introduction
Земля NI cRIO-9058 is an 8-slot CompactRIO embedded controller designed for industrial control, distributed data acquisition, condition monitoring, machine automation, hardware-in-the-loop testing, and rugged embedded measurement applications.
The cRIO-9058 combines a 1.33 GHz dual-core Intel Atom processor, 2 ГБ ОЗУ, 4 GB internal storage, a user-programmable Artix-7 A100T FPGA, and eight slots for compatible C Series I/O modules.
The controller runs NI Linux Real-Time and supports access to compatible C Series I/O through NI-DAQmx or FPGA-based programming. It also provides two Gigabit Ethernet ports, Time Sensitive Networking (TSN), USB connectivity, a trigger line, and a microSD card slot for local data storage.
Product Overview
Земля National Instruments cRIO-9058 combines real-time processing, FPGA-based deterministic I/O, modular C Series hardware, local storage, and industrial networking in a rugged embedded controller.
A typical CompactRIO architecture is:
Sensors / Actuators → C Series Modules → FPGA / NI-DAQmx → Real-Time Processor → Ethernet / Storage / Host System
Its eight-slot architecture provides enough capacity to combine several measurement and control functions within one embedded platform.
Типичные применения включают:
- Industrial control
- Распределенный сбор данных
- Machine monitoring
- Мониторинг состояния
- Hardware-in-the-loop testing
- Automotive validation
- Энергетические системы
- Structural monitoring
- Remote data logging
- Автоматизированные системы тестирования
Key Features
8-Slot CompactRIO Controller
The cRIO-9058 provides eight slots for compatible C Series I/O modules.
The modular C Series architecture allows the same controller to be configured for many different applications by selecting the required measurement and control modules.
C Series module categories can include:
- Analog input
- Analog output
- Digital input
- Digital output
- Измерение температуры
- Dynamic signal acquisition
- Измерение деформации и растяжения
- Relay control
- Communication interfaces
- Counter and timer modules
- Specialty I/O
1.33 GHz Dual-Core Processor
The cRIO-9058 uses a 1.33 GHz dual-core Intel Atom processor.
The embedded processor runs the NI Linux Real-Time operating system and can execute applications independently of a continuously connected host computer.
Typical processor-level tasks include:
- Real-time control loops
- Регистрация данных
- Alarm processing
- Сетевая связь
- Data analysis
- System diagnostics
- File management
- Application-level decision logic
2 ГБ ОЗУ
The cRIO-9058 provides 2 GB of processor DRAM.
This memory supports NI Linux Real-Time, deployed applications, networking, data processing, and measurement buffering.
4 GB Internal Storage
The controller includes 4 GB of internal storage.
Internal storage can be used for:
- Operating system files
- Deployed applications
- Configuration files
- Регистрация данных
- Diagnostic information
Artix-7 A100T FPGA
The cRIO-9058 includes a user-programmable Xilinx Artix-7 A100T FPGA.
The FPGA provides deterministic hardware execution for timing-critical measurement and control applications.
Typical FPGA functions include:
- Custom triggering
- High-speed digital I/O
- Обработка кодировщика
- Генерация ШИМ
- Signal preprocessing
- Hardware interlocks
- Пользовательские цифровые протоколы
- Fast control loops
- Deterministic event detection
Real-Time Processor and FPGA Architecture
The cRIO-9058 allows engineers to divide application tasks between the real-time processor and FPGA.
A typical allocation is:
FPGA → Precise Timing, High-Speed I/O, Hardware Logic
Real-Time Processor → Control Algorithms, Logging, Analysis and Networking
This architecture combines software flexibility with deterministic hardware execution.
NI Linux Real-Time
The cRIO-9058 runs NI Linux Real-Time, providing a deterministic embedded operating environment for measurement and control applications.
Once software is deployed, the controller can operate independently as a standalone embedded system.
NI-DAQmx Support
The cRIO-9058 supports НИ-DAQmx for compatible C Series modules.
NI-DAQmx can simplify standard data acquisition applications by allowing engineers to access supported C Series I/O without developing custom FPGA code for every measurement task.
Depending on the selected module and application architecture, I/O can be accessed using:
- НИ-DAQmx
- Real-Time Scan architecture
- LabVIEW FPGA
LabVIEW FPGA Support
Applications requiring custom hardware functionality can program the onboard Artix-7 FPGA using compatible LabVIEW FPGA software.
FPGA programming is useful for:
- Custom protocols
- Deterministic machine control
- Hardware-in-the-loop testing
- Custom triggering
- Генерация импульсов
- Интерфейсы энкодера
- High-speed I/O processing
Two Gigabit Ethernet Ports
The cRIO-9058 provides two Gigabit Ethernet ports.
Dual Ethernet connectivity supports flexible network architectures for:
- Host communication
- Remote monitoring
- Distributed measurement
- Network segmentation
- Data transfer
- TSN-based synchronization
Time Sensitive Networking
The cRIO-9058 supports Time Sensitive Networking (TSN).
TSN provides precise hardware-based timing synchronization over Ethernet and is particularly valuable in distributed measurement and control systems.
Applications can include:
- Distributed DAQ
- Multi-controller systems
- Синхронизация машины
- Structural monitoring
- Remote measurement nodes
IEEE 802.1AS Synchronization
The TSN architecture supports hardware-based time synchronization using IEEE 802.1AS.
This enables compatible networked devices to operate from a coordinated time reference.
USB 3.1 Host Port
The cRIO-9058 provides a USB 3.1 host port for compatible peripherals and storage devices.
The port can support local expansion, system maintenance, peripheral connections, and data-transfer applications.
USB 2.0 Device Port
A USB 2.0 device port is also provided for controller configuration, deployment, and local connection to a host computer.
MicroSD Card Slot
The cRIO-9058 includes a microSD card slot for removable local storage.
This is useful for applications such as:
- Long-term data logging
- Remote monitoring
- Field measurement
- Standalone acquisition
- Measurement file transfer
Trigger Line
The cRIO-9058 provides a dedicated trigger line that can be used as part of synchronized measurement and control applications.
Trigger functionality can help coordinate the controller with external test equipment or distributed measurement nodes.
Extended -40 °C to 70 °C Operating Range
The cRIO-9058 is designed for operation from approximately -40 °C до 70 °C.
This extended temperature capability makes the controller suitable for many industrial, transportation, remote monitoring, and embedded applications.
9 VDC to 30 VDC Power Input
The cRIO-9058 accepts a DC power input from approximately 9 В постоянного тока до 30 В постоянного тока.
NI specifies a maximum controller power consumption of approximately 30 W under fully loaded high-stress operating conditions.
A 24 VDC, 60 W external power supply is recommended for typical system integration.
Conformal Coating Option
The cRIO-9058 is available in both standard and conformal-coated ordering configurations.
The conformal-coated version includes a protective coating over the electronics to provide additional resistance to environmental contaminants and moisture exposure in compatible industrial applications.
Technical Specifications
| Параметр | Спецификация |
|---|---|
| Product Type | Компактный контроллерRIO |
| Модель | NI cRIO-9058 |
| Part Numbers | 787044-01 / 787880-01 |
| Platform | CompactRIO |
| C Series Slots | 8 |
| Процессор | Intel Atom с двумя ядрами |
| Частота процессора | 1.33 GHz |
| Processor DRAM | 2 GB |
| Internal Storage | 4 GB |
| Операционная система | NI Linux Real-Time |
| ФПГА | Xilinx Artix-7 A100T |
| FPGA Programming | Supported |
| НИ-DAQmx | Supported with Compatible C Series Modules |
| Ethernet-порты | 2 |
| Ethernet Speed | Гигабитный Ethernet |
| ТСН | Supported |
| Network Time Synchronization | IEEE 802.1AS |
| USB Host | USB 3.1 |
| USB Device | USB 2.0 |
| Removable Storage | MicroSD Card Slot |
| Trigger Line | 1 |
| Power Input | 9 В постоянного тока до 30 В постоянного тока |
| Maximum Power Consumption | 30 W |
| Recommended Power Supply | 24 VDC, 60 W |
| Operating Temperature | -40 °C до 70 °C |
| Dimensions | 328.7 mm × 82.5 mm × 189.6 mm |
| Approximate Unloaded Weight | 1.604 kg |
| Primary Applications | Industrial Control, Distributed DAQ, Condition Monitoring, HIL Test and Embedded Measurement |
cRIO-9058 Part Numbers
The cRIO-9058 is currently available in two NI ordering configurations.
| Part Number | Конфигурация | Status |
|---|---|---|
| 787044-01 | Standard cRIO-9058 | Active |
| 787880-01 | cRIO-9058 with Conformal Coating | Active |
The processor, memory, FPGA, slot count, and core connectivity are the same between these configurations. The primary ordering difference is the conformal coating.
787044-01 cRIO-9058
NI part number 787044-01 identifies the standard cRIO-9058 configuration without conformal coating.
It includes the 1.33 GHz dual-core CPU, 2 GB DRAM, 4 GB storage, Artix-7 A100T FPGA, eight C Series slots, dual Gigabit Ethernet, TSN, USB, and microSD support.
787880-01 cRIO-9058
NI part number 787880-01 identifies the conformal-coated cRIO-9058 configuration.
Conformal coating can provide additional protection for electronics used in demanding industrial environments where moisture or contamination resistance is important.
What Is CompactRIO?
CompactRIO is a modular embedded measurement and control platform from National Instruments.
A CompactRIO controller combines:
- Real-time processor
- ФПГА
- Модульные устройства ввода-вывода серии C
- Industrial networking
- Embedded operating system
This architecture allows a CompactRIO system to perform measurement, control, processing, networking, and logging without depending on a continuously connected desktop computer.
How Does the cRIO-9058 Work?
Sensors and actuators connect to compatible C Series modules installed in the eight-slot controller.
Depending on the application, the I/O can be accessed through NI-DAQmx or processed using custom FPGA logic.
The real-time processor handles higher-level control, logging, networking, and application management.
A typical signal path is:
Sensor → C Series Module → FPGA / NI-DAQmx → Real-Time Application → Storage / Ethernet / Output
cRIO-9058 for Data Acquisition
The eight C Series slots allow the cRIO-9058 to be configured as a versatile embedded data acquisition platform.
Depending on the installed modules, measurements can include:
- Voltage
- Current
- Temperature
- Термопары
- РТД
- Strain
- Pressure
- Acceleration
- Vibration
- Звук
- Digital signals
cRIO-9058 for Industrial Control
The combination of real-time processing and FPGA hardware makes the cRIO-9058 suitable for deterministic industrial control applications.
Типичные применения включают:
- Machine automation
- Process control
- Встроенное управление
- Управление испытательным стендом
- Industrial monitoring
- Custom machine interfaces
- Safety-related monitoring logic
Мониторинг состояния
The cRIO-9058 can be combined with compatible C Series dynamic signal, temperature, and digital modules to create machine condition-monitoring systems.
Typical monitored parameters include:
- Vibration
- Acceleration
- Temperature
- Rotational speed
- Pressure
- Acoustic signals
Data can be processed locally before being stored or transmitted over Ethernet.
Distributed Data Acquisition
The dual Gigabit Ethernet ports and TSN support make the cRIO-9058 particularly suitable for distributed measurement applications.
Multiple synchronized controllers or measurement nodes can be placed near sensors and linked through Ethernet.
A simplified architecture is:
cRIO Node 1 ↔ TSN Ethernet ↔ cRIO Node 2 ↔ Additional Measurement Nodes
This can reduce long analog cable runs and simplify large distributed test systems.
Hardware-in-the-Loop Testing
The cRIO-9058 can be used in compatible hardware-in-the-loop test systems where deterministic I/O and real-time execution are required.
Typical HIL functions can include:
- Digital sensor simulation
- Генерация ШИМ
- Encoder simulation
- Actuator monitoring
- Пользовательские протоколы связи
- Real-time event processing
- Controller validation
FPGA-Based Control
The Artix-7 A100T FPGA allows timing-sensitive algorithms to execute directly in hardware.
FPGA applications may include:
- Hardware interlocks
- Custom triggering
- High-speed digital acquisition
- Измерение пульса
- Custom counters
- Encoder decoding
- PWM
- Deterministic response logic
Real-Time Processor vs FPGA
| Function | Real-Time Processor | ФПГА |
|---|---|---|
| Execution Type | Software | Hardware Parallel Logic |
| Control Algorithms | Excellent | Supported |
| High-Speed Timing | Good | Excellent |
| Custom Digital Protocols | Software Based | Hardware Based |
| Networking | Primary Resource | Application Dependent |
| Data Logging | Primary Resource | Usually Transfers Data to Processor |
NI-DAQmx vs FPGA Programming
| Функция | НИ-DAQmx | LabVIEW FPGA |
|---|---|---|
| Standard Data Acquisition | Excellent | Supported |
| Development Complexity | Lower | Higher |
| Custom Timing | Supported Functions | Highly Customizable |
| Custom Protocols | Ограниченный | Excellent |
| Hardware Logic | No User FPGA Logic | Fully Programmable |
C Series Module Compatibility
The cRIO-9058 supports a wide range of compatible C Series I/O modules.
Common module categories include:
- C Series Analog Input Modules
- C Series Analog Output Modules
- C Series Temperature Measurement Modules
- C Series Dynamic Signal Modules
- C Series Digital Input Modules
- C Series Digital Output Modules
- C Series Relay Modules
- C Series Communication Modules
- C Series Counter Modules
- C Series Specialty Modules
Exact compatibility should be verified for the individual C Series module, software version, and selected operating mode.
Analog Input Applications
Compatible C Series analog input modules allow the cRIO-9058 to acquire industrial, sensor, and test signals.
Examples include:
- Voltage signals
- Current loops
- Pressure sensors
- Bridge sensors
- Промышленные передатчики
- Power signals
Temperature Measurement
Compatible thermocouple and RTD C Series modules allow the cRIO-9058 to be configured for embedded temperature monitoring.
Области применения включают:
- Machine temperature monitoring
- Battery thermal testing
- Экологические испытания
- Industrial processes
- Thermal validation
Vibration Measurement
Dynamic signal acquisition modules can be installed for vibration and acoustic measurements.
A typical system may include:
Accelerometers → C Series Dynamic Signal Module → cRIO-9058 → Local Analysis / Storage / Ethernet
This architecture is useful for machine health monitoring and predictive maintenance.
Digital I/O Applications
Compatible C Series digital modules can provide digital input and output functions for industrial equipment.
Applications can include:
- Switch monitoring
- Relay control
- Encoder signals
- Измерение пульса
- Генерация ШИМ
- Machine status monitoring
- Interlocks
Standalone Data Logging
The combination of internal storage and microSD support makes the cRIO-9058 suitable for standalone data-logging applications.
A typical architecture is:
Sensors → C Series Modules → cRIO-9058 → Internal / MicroSD Storage
Recorded data can later be transferred to a host system through Ethernet or USB.
Remote Monitoring
The rugged embedded architecture and dual Ethernet connectivity make the cRIO-9058 suitable for remote monitoring installations.
The controller can acquire and analyze measurement data locally, transmitting only required information to a supervisory computer or server.
cRIO-9058 vs cRIO-9046
The cRIO-9058 and cRIO-9046 are both 8-slot CompactRIO controllers, but they use different FPGA and processor generations.
| Функция | cRIO-9058 | cRIO-9046 |
|---|---|---|
| C Series Slots | 8 | 8 |
| Частота процессора | 1.33 GHz | 1.30 GHz |
| DRAM | 2 GB | 2 GB |
| Хранение | 4 GB | 4 GB |
| ФПГА | Artix-7 A100T | Кинтекс-7 70Т |
| C Series Slots | 8 | 8 |
| ТСН | Да | Да |
| Primary Selection Basis | FPGA Architecture, Software Compatibility, C Series Requirements and Existing System Platform | |
cRIO-9058 vs cRIO-9048
Both controllers provide eight C Series slots and support real-time, FPGA, and TSN-based architectures, but their FPGA and storage resources differ.
| Функция | cRIO-9058 | cRIO-9048 |
|---|---|---|
| C Series Slots | 8 | 8 |
| Частота процессора | 1.33 GHz | 1.30 GHz |
| DRAM | 2 GB | 2 GB |
| Internal Storage | 4 GB | 8 GB |
| ФПГА | Artix-7 A100T | Кинтекс-7 160Т |
| Best Selection Basis | FPGA Resource Requirements, Software Compatibility, Storage and Existing CompactRIO Architecture | |
cRIO-9058 vs Traditional PLC
| Функция | cRIO-9058 | Traditional PLC |
|---|---|---|
| Real-Time Processor | Да | Да |
| User-Programmable FPGA | Да | Usually No |
| Advanced Measurement I/O | Extensive C Series Options | Typically More Limited |
| Custom Hardware Timing | Excellent | More Limited |
| Industrial Control | Да | Да |
| Distributed Measurement | Strong TSN Integration | Platform Dependent |
cRIO-9058 vs PC-Based DAQ
| Функция | cRIO-9058 | PC-Based DAQ |
|---|---|---|
| Standalone Operation | Да | Usually Requires PC |
| Real-Time OS | NI Linux Real-Time | Usually Desktop OS |
| User FPGA | Да | Hardware Dependent |
| Operating Temperature | -40 °C до 70 °C | Hardware Dependent |
| Modular I/O | C Series | Platform Dependent |
Conformal Coating vs Standard Version
| Функция | 787044-01 | 787880-01 |
|---|---|---|
| Модель | cRIO-9058 | cRIO-9058 |
| Процессор | 1.33 GHz Dual-Core | 1.33 GHz Dual-Core |
| ФПГА | Artix-7 A100T | Artix-7 A100T |
| C Series Slots | 8 | 8 |
| Conformal Coating | No | Да |
| Typical Selection | Standard Industrial Applications | Harsh or Contaminated Environments |
Power Supply Considerations
The cRIO-9058 accepts approximately 9 В постоянного тока до 30 В постоянного тока at its power input.
NI recommends a 24 VDC, 60 W supply for typical system installation.
Actual system power requirements depend on:
- Installed C Series modules
- USB devices
- Application processing load
- Operating temperature
- FPGA utilization
How to Choose a CompactRIO Controller
Before selecting the cRIO-9058, engineers should evaluate:
- Required number of C Series slots
- Processor performance
- FPGA resource requirements
- RAM requirements
- Storage requirements
- Need for removable microSD storage
- Ethernet port requirements
- TSN synchronization requirements
- NI-DAQmx requirements
- LabVIEW FPGA requirements
- Operating temperature
- Conformal coating requirements
- Power input requirements
- C Series module compatibility
Software and Programming
The cRIO-9058 can be used with compatible NI software environments for data acquisition, real-time control, FPGA programming, and embedded system development.
Software options can include:
- ЛабВью
- LabVIEW Real-Time
- LabVIEW FPGA
- НИ-DAQmx
- FlexLogger
- Compatible NI system configuration tools
Software compatibility should be verified for the specific hardware revision, C Series modules, and target application.
Industries
- Промышленная автоматизация
- Automotive Testing
- Энергетические системы
- Мониторинг состояния
- Machine Control
- Аэрокосмическая и оборонная промышленность
- Transportation
- Structural Monitoring
- Embedded Systems
- Research and Development
Applications
Industrial Control
The cRIO-9058 combines real-time processing, FPGA logic, and modular C Series I/O for deterministic industrial control applications.
Data Acquisition
Eight C Series slots provide flexible measurement capability for voltage, current, temperature, strain, vibration, digital, and other signals.
Distributed Measurement
Dual Gigabit Ethernet and TSN support allow multiple measurement nodes to be synchronized across an Ethernet network.
Мониторинг состояния
Dynamic signal, temperature, and digital C Series modules can be combined for machine health and predictive maintenance systems.
Hardware-in-the-Loop Testing
The real-time processor and FPGA architecture support deterministic I/O and controller-validation applications.
Standalone Data Logging
Internal storage and a microSD card slot allow the cRIO-9058 to log measurement data locally without requiring continuous host communication.
Harsh-Environment Monitoring
The -40 °C to 70 °C operating range and optional conformal coating make the cRIO-9058 suitable for many demanding industrial and remote installations.
Recommended Related Products
| NI cRIO-9058 | 8-slot CompactRIO controller with 1.33 GHz dual-core processor, Artix-7 A100T FPGA, 2 GB DRAM, dual Gigabit Ethernet, TSN, and microSD storage. |
| NI cRIO-9046 | 8-slot CompactRIO controller using a Kintex-7 70T FPGA for embedded measurement and industrial control applications. |
| NI cRIO-9048 | 8-slot CompactRIO controller with a Kintex-7 160T FPGA and larger internal storage for applications requiring additional FPGA and storage resources. |
| NI C Series Analog Input Modules | Modular analog measurement hardware for voltage, current, sensor, and industrial data acquisition. |
| NI C Series Digital Input Modules | Industrial digital input modules for machine status, logic, pulse, and control-system monitoring. |
| NI C Series Digital Output Modules | Digital output modules for industrial control, relay driving, machine automation, and embedded test systems. |
Why Choose NI cRIO-9058?
- 8 C Series I/O slots
- 1.33 GHz dual-core Intel Atom processor
- 2 GB processor DRAM
- 4 GB internal storage
- Artix-7 A100T FPGA
- NI Linux Real-Time
- NI-DAQmx support
- LabVIEW FPGA support
- Two Gigabit Ethernet ports
- TSN and IEEE 802.1AS synchronization
- USB 3.1 host connectivity
- USB 2.0 device connectivity
- MicroSD removable storage
- Dedicated trigger line
- 9 В постоянного тока до 30 В постоянного тока на входе питания
- -40 °C to 70 °C operating range
- Optional conformal coating
- Suitable for industrial and distributed measurement
Frequently Asked Questions
What is the NI cRIO-9058?
The NI cRIO-9058 is an 8-slot CompactRIO embedded controller featuring a 1.33 GHz dual-core processor, 2 GB DRAM, 4 GB storage, an Artix-7 A100T FPGA, dual Gigabit Ethernet, TSN, and modular C Series I/O support.
What are the part numbers of the cRIO-9058?
NI currently lists 787044-01 и 787880-01 for the cRIO-9058.
What is the difference between 787044-01 and 787880-01?
Both have the same core cRIO-9058 hardware configuration. 787880-01 includes conformal coating, while 787044-01 is the standard non-coated version.
How many C Series slots does the cRIO-9058 have?
The cRIO-9058 provides eight C Series module slots.
What processor does the cRIO-9058 use?
The cRIO-9058 uses a 1.33 GHz dual-core Intel Atom processor.
How much RAM does the cRIO-9058 have?
The controller provides 2 GB of processor DRAM.
How much internal storage does the cRIO-9058 have?
The cRIO-9058 provides 4 GB of internal storage.
What FPGA does the cRIO-9058 use?
The cRIO-9058 uses a Xilinx Artix-7 A100T FPGA.
Does the cRIO-9058 support NI-DAQmx?
Yes. Compatible C Series modules can be accessed through NI-DAQmx for standard data acquisition applications.
Does the cRIO-9058 support LabVIEW FPGA?
Yes. The onboard Artix-7 FPGA can be programmed using compatible LabVIEW FPGA software.
Does the cRIO-9058 support TSN?
Yes. The cRIO-9058 supports Time Sensitive Networking and IEEE 802.1AS-based hardware time synchronization.
How many Ethernet ports does the cRIO-9058 have?
The controller provides two Gigabit Ethernet ports.
Does the cRIO-9058 have a microSD card slot?
Yes. The controller includes a microSD card slot for removable local storage and data logging.
Does the cRIO-9058 support USB 3.1?
Yes. The cRIO-9058 provides one USB 3.1 host port and one USB 2.0 device port.
What is the power input range of the cRIO-9058?
NI specifies an input range of approximately 9 В постоянного тока до 30 В постоянного тока.
What power supply is recommended for the cRIO-9058?
NI recommends approximately 24 VDC, 60 W for system power, although actual requirements depend on the installed C Series modules and connected peripherals.
What is the operating temperature of the cRIO-9058?
The controller is specified for operation from approximately -40 °C до 70 °C.
Can the cRIO-9058 operate without a PC?
Yes. Once an application is deployed, the cRIO-9058 can operate independently as a standalone real-time embedded controller.
Can the cRIO-9058 be used for condition monitoring?
Yes. Compatible vibration, temperature, analog, and digital C Series modules can be used to build embedded machine-condition and asset-monitoring systems.
Can the cRIO-9058 be used for HIL testing?
Yes. The real-time processor, FPGA, and modular I/O architecture make the cRIO-9058 suitable for compatible hardware-in-the-loop and controller-validation applications.
Can the cRIO-9058 be used in harsh environments?
Yes. It is specified for -40 °C to 70 °C operation, and the 787880-01 configuration adds conformal coating for applications requiring additional environmental protection.
What should I check before purchasing a cRIO-9058?
Before purchasing the cRIO-9058, verify the required C Series slot count, FPGA resources, processor performance, NI-DAQmx and LabVIEW FPGA requirements, Ethernet and TSN requirements, storage capacity, operating temperature, power input, C Series module compatibility, software version, and whether the standard 787044-01 or conformal-coated 787880-01 configuration is appropriate.
Заключение
Земля NI cRIO-9058 8-Slot CompactRIO Controller combines a 1.33 GHz dual-core processor, 2 GB DRAM, 4 GB storage, an Artix-7 A100T FPGA, eight C Series I/O slots, dual Gigabit Ethernet, TSN, USB connectivity, microSD storage, and an extended -40 °C to 70 °C operating range. With both standard and conformal-coated versions available, the cRIO-9058 is well suited for industrial control, distributed data acquisition, condition monitoring, hardware-in-the-loop testing, remote data logging, machine automation, and rugged embedded measurement systems.
