PXIe-4339

The PXIe‑4339 is a universal bridge input module ideal for test cell installations requiring both accuracy and flexibility. Completely configurable through software, each channel can take bridge-based measurements and direct voltage measurements. Eight input ranges in ratiometric mode and four in voltage mode accommodate a wide variety of sensor types for your changing application needs. The PXIe‑4339 also features per-channel wide bandwidth analog outputs, programmable excitation, Transducer Electronic Data Sheet (TEDS) support, and digital filtering.

Applications and Use Cases of PXIe-4339

The PXIe-4339 Bridge Input Module is a PXI Express bridge input measurement module предназначен для high-precision strain, load, and bridge-based sensor measurements. Она предоставляет high-resolution acquisition, bridge completion, excitation, and synchronized sampling, что делает его идеальным для structural testing, durability analysis, and industrial sensor applications.

1. Strain Gauge Measurement
PXIe-4339 is optimized for measuring strain gauge signals with high precision, commonly used in structural and mechanical testing.

2. Bridge Sensor Acquisition
Supports full-bridge, half-bridge, and quarter-bridge transducers such as load cells, pressure sensors, and torque sensors.

3. Structural Health & Durability Testing
Used to monitor stress, deformation, vibration, and fatigue in mechanical structures and components.

4. Load, Force & Torque Measurement
Widely applied in systems requiring accurate force, weight, and torque monitoring.

5. Industrial Monitoring & Process Control
Used in industrial environments for monitoring mechanical performance and process conditions.

6. Автоматизированное испытательное оборудование (АИО)
Integrated into synchronized test systems for sensor validation and mechanical/electrical testing.

7. Научные и лабораторные применения
Used in labs for material testing, structural analysis, and precision sensor research.
